MK650B 4K Laser Projector

A bright, razor-sharp 4K laser projector built to elevate any golf simulator setup.

The MK650B delivers 6,500 lumens of true 4K UHD clarity, so your course visuals stay vivid even in rooms with ambient light. Flexible lens shift, interchangeable lens options, and a long-life ALPD® laser engine mean it installs cleanly and holds up under serious use.

Highly ll-Lumen-ating

Whether you're practicing in a garage with the door open or hosting a round in a commercial simulator bay, the MK650B's 6,500 lumens ensure your image stays clear and Brilliant. The Added brightness enhances course detail, improves visibility of ball flight, and creates a more realistic playing experience

It's All in the Lens

Featuring a high-performance, exclusive lens system, the appotronics MK650B delivers sharp focus and detailed imagery across the entire screen for a consistently immersive golf simulator experience

AIPQ and MEMC

AI picture Quality (AI PQ) and Motion Estimation, Motion Compensation (MEMC) work together to optimize image clarity and deliver ultra-smooth visuals for more true-to-life golf simulator Experience

True 4K UHD Resolution (3840×2160)
Sharp ball definition, clean edges, and detailed course textures — easier to track and analyze, whether you're dialing in yardages or playing full rounds in E6 or GSPro.

ALPD® Laser Light Engine
Advanced Laser Phosphor Display produces a bright, high-contrast image with accurate color, and holds up in rooms with ambient light — no need for a fully dark room.

Fully Sealed Optical Engine (IP6X Rated)
Patented internal cooling and a dust-proof optical engine keep it running cooler and cleaner, with less maintenance over the long run.

Short Throw
Built to fit into a simulator setup without getting in the way. The short throw distance allows for flexible mounting while preserving swing space and sightlines.

Built for Better Golf Sim Performance
The ALPD® laser engine and motion compensation work together to minimize blur during fast swings, so every fairway, green, and ball flight stays sharp and true to life.

Appotronics MK650B Specifications

Spec	Detail
Projection System	DLP™
Resolution	3840 × 2160 (4K UHD)
Brightness	6,500 lumens
Native Aspect Ratio	16:9
Contrast Ratio (FOFO)	100,000:1
Keystone Adjustment	Vertical ±35°, Horizontal ±35°
Lens Shift Vertical	Down 60%, Up 100% (ceiling mounted)
Lens Shift Horizontal	±40% powered
Warping	Yes, via multi-point correction
Light Source	Laser (ALPD® technology)
Light Source Life	Up to 20,000 hours
Throw Ratio	0.7–0.9
Zoom Ratio	1.3× powered
Connections	HDMI in ×2, HDMI out ×1, S/PDIF ×1, USB-A ×2, USB-B ×1, RS-232 (DB9) ×1, RJ-45 LAN ×1, 3D Sync ×2, 3D IR Out ×1
Dimensions	5.43" × 18.11" × 15.28"
Net Weight	27.5 lbs
Internal Speakers	Yes

Mounting Options

Flush to the ceiling — Stays clear of the swing path and minimizes shadows for a clean setup.

Drop mount — For high ceilings or precise height adjustments, lowers the projector to the ideal viewing height.

Enclosure mount — Mounts directly to the frame of a Carl's Place Pro Enclosure for a sturdy, streamlined setup.

What's in the Box

Appotronics MK650B projector
Remote
Power cord
Lens (pre-installed)
